Tournage arrière
633 / 643 Rückwärts drehen
Back turning

L R

R
E2 E1 L
2.5°
R
3° E L1 20°

L R

P P P P
M M M M
N N N N N N N N
S S S S

E1 E2 L L1 E R Art. N° TiAlN N (µk20) HTA HN (µk10) Art. N° TiAlN N (µk20) HTA HN (µk10)
0.5 0.25 3 2.8 1.5 0 633-0.5   643-0.5   
0.5 0.25 3 2.8 1.5 0.08 - 643-0.5-R08  
0.8 0.40 4.5 3.3 2.0 0 - 643-0.8  
0.8 0.40 4.5 3.3 2.0 0.08 - 643-0.8-R08  
1.0 0.40 5 4.2 2.5 0 - 643-1.0  
1.0 0.40 5 4.2 2.5 0.08 - 643-1.0-R08  
1.5 0.50 6 4.2 3.0 0 - 643-1.5  
1.5 0.50 6 4.2 3.0 0.08 - 643-1.5-R08  

5.18
