Plaquettes de tronçonnage
Abstechwendeplatten UL-UR
Cut off inserts

24

R

E
R

A

UL UR

P P P P P P
M M M M M M
N N
S S

Type E ±0.05 A R Art. N° TiAlN Tmax Zmax Art. N° TiAlN Tmax Zmax
1.5 6° 0.2 - ET15-UR-602   
1.35 8° 0 - ET15-UR-800F 
ET15
1.5 12° 0.1 - ET15-UR-1201   
1.35 15° 0 ET15-UL-1500F  ET15-UR-1500F 
2.0 6° 0.2 - ET20-UR-602   
1.85 8° 0 - ET20-UR-800F 
ET20
2.0 12° 0.1 - ET20-UR-1201   
1.85 15° 0 ET20-UL-1500F  ET20-UR-1500F 
2.5 6° 0.2 - ET25-UR-602   
2.35 8° 0 - ET25-UR-800F 
ET25
2.5 12° 0.1 - ET25-UR-1201   
2.35 15° 0 ET25-UL-1500F  ET25-UR-1500F 
3.0 6° 0.3 - ET30-UR-603   
2.85 8° 0 - ET30-UR-800F 
ET30
3.0 12° 0.2 - ET30-UR-1202   
2.85 15° 0 ET30-UL-1500F  ET30-UR-1500F 

10.27
