           Codification des porte-outils                                   BH-D / BHS
           Kodifizierung für Halter
           Coding guide for holders                                    BHS-D / BHY-D























                   H                          HS                           H  Y






                          B     H     4     –     D     2  0  –    1  0  0




                                                                  Longueur
                                                                  Länge
                                                                  Length

                                                      Ø/ Q / queue
                                                      Schaft Ø/ Q /
                                                      Shank Ø/ Q /


                                             Queue cylindrique
                                             Zylindrischer Schaft
                                             Cylindrical shank



                                      Ø alésage
                                      Bohrung Ø
                                      Bore Ø

                                Porte-outils
                                Halter
                                Holders

                        Ligne produit d’alésage
                        Innendrehen Produktlinie
                        Boring product line
