Index 750 / 760
Fonçage-tournage
Einstechen und drehen 754 / 764
Grooving and turning

L R

R E L
1°
R
1° 8

L R

P P P P P P P P P P P P P
M M M M M M M M M
N N N N N N N N N N
S S S S S S S S S
TiAlN N (µk20) HN (µk10) TiAlN TiAlX N (µk20) HN (µk10)
E L R Art. N° TiN HTA HTiN Art. N° TiN HTA HTiN
0.5 1.5 0 754-0.5    764-0.5       
0.75 2 0 754-0.75    764-0.75    
0.8 2 0 - 764-0.8      
0.95 3 0 754-0.95      764-0.95    
1.0 2.5 0 754-1.0      764-1.0       
1.0 2.5 0.08 754-1.0-R08    764-1.0-R08      
1.2 3 0 754-1.2    764-1.2      
1.5 3 0 754-1.5      764-1.5       
1.5 3 0.08 754-1.5-R08      764-1.5-R08      
1.5 3 0.15 - 764-1.5-R15     
1.5 3 0.20 - 764-1.5-R20       
1.8 4 0 754-1.8    764-1.8    
2.0 4 0 754-2.0       764-2.0       
2.0 4 0.08 754-2.0-R08      764-2.0-R08      
2.0 4 0.15 - 764-2.0-R15     
2.0 4 0.20 754-2.0-R20    764-2.0-R20       
2.5 6 0 754-2.5    764-2.5      
2.5 6 0.15 - 764-2.5-R15     
2.5 6 0.20 - 764-2.5-R20      
3.0 6 0 754-3.0      764-3.0      
3.0 6 0.08 754-3.0-R08    764-3.0-R08      
3.0 6 0.15 - 764-3.0-R15     
3.0 6 0.20 754-3.0-R20      764-3.0-R20    
4.0 8 0 754-4.0       764-4.0      
1.147
