Index 750 / 760
Fonçage-tournage
Einstechen und drehen 754X / 764X
Grooving and turning

L R
10°

R E L
1°
R
1°
8

L R

P P P P P P P P P P P P P P
M M M M M M M M M M
N N N N N N N N N N N
S S S S S S S S S S
TiAlN N (µk20) HN (µk10) TiAlN TiAlX N (µk20) HN (µk10)
E L R Art. N° TiN HTA HTiN Art. N° ST TiN HTA HTiN
1.0 2.5 0 754X-1.0       764X-1.0      
1.0 2.5 0.08 754X-1.0-R08      764X-1.0-R08        
1.0 2.5 0.20 - 764X-1.0-R20     
1.2 3 0 754X-1.2    764X-1.2      
1.2 3 0.08 - 764X-1.2-R08     
1.5 3 0 754X-1.5      764X-1.5       
1.5 3 0.08 754X-1.5-R08      764X-1.5-R08       
1.5 3 0.15 - 764X-1.5-R15      
1.5 3 0.20 754X-1.5-R20    764X-1.5-R20        
1.8 4 0 754X-1.8    764X-1.8      
1.8 4 0.20 - 764X-1.8-R20     
2.0 4 0 754X-2.0      764X-2.0       
2.0 4 0.08 754X-2.0-R08      764X-2.0-R08        
2.0 4 0.15 - 764X-2.0-R15      
2.0 4 0.20 754X-2.0-R20      764X-2.0-R20       
2.0 4 0.35 - 764X-2.0-R35      
2.5 6 0 754X-2.5       764X-2.5       
2.5 6 0.15 - 764X-2.5-R15      
2.5 6 0.20 754X-2.5-R20      764X-2.5-R20       
2.5 6 0.35 - 764X-2.5-R35      
3.0 6 0 754X-3.0    764X-3.0      
3.0 6 0.08 754X-3.0-R08    764X-3.0-R08       
3.0 6 0.15 - 764X-3.0-R15       
3.0 6 0.20 754X-3.0-R20    764X-3.0-R20       
3.0 6 0.35 - 764X-3.0-R35      
4.0 8 0 754X-4.0    764X-4.0      
4.0 8 0.20 754X-4.0-R20    764X-4.0-R20       
4.0 8 0.35 - 764X-4.0-R35      
1.149
