Fonçage-tournage
Einstechen und drehen 254X / 264X
Grooving and turning

R
L L R
10°
0.5°
0.2° E
L1
R

L R

P P P P P
M M M M M
N N N N N N N N
S S S S S
AP302 AP202 N (µk20) AP302 AP202 N (µk20) AH302 HN (µk10)
E L L 1 R Art. N° Art. N°
0 . 8 2 4 0 254X-0.8    264X-0.8   
1.0 2.5 4 0 254X-1.0    264X-1.0   
1.0 2.5 4 0.08 - 264X-1.0-R08     
1 . 2 3 4 0 254X-1.2    264X-1.2   
1 . 5 3 4 0 254X-1.5    264X-1.5  
1.5 3 4 0.08 - 264X-1.5-R08     
1.5 3 4 0.20 - 264X-1.5-R20     
2.0 4 6.5 0 254X-2.0   264X-2.0   
2.0 4 6.5 0.08 - 264X-2.0-R08     
2.0 4 6.5 0.20 - 264X-2.0-R20    
2.5 6 6.5 0 254X-2.5    264X-2.5   
2.5 6.5 6.5 0.08 - 264X-2.5-R08     
2.5 6.5 6.5 0.20 - 264X-2.5-R20     
3.0 6.5 6.5 0 254X-3.0    264X-3.0  
3.0 6.5 6.5 0.08 - 264X-3.0-R08     
3.0 6.5 6.5 0.20 - 264X-3.0-R20     

6.25
