Index 730 / 740
Porte-outils
Halter 740 / 730-D
Holders
A
B D 20
(30) L
R L
A x B L D Art. N°
19 x 17 160 16 740/730-D16
19 x 17 160 19.05 740/730-D19.05
19 x 17 110 19.05 740/730-D19.05-S
19.5 x 17 160 20 740/730-D20
20 x 17 110 22 740/730-D22
22 x 17 200 25 740/730-D25
22 x 17 200 25.4 740/730-D25.4
D
A
B 30 22
(30) L
R L
A x B L D Art. N°
19 x 17 52 10 740/730-D10
Chaque support est livré avec une ou plusieurs vis. Les clés sont à commander séparément.
Jeder Halter wird mit einer oder mehreren Schrauben geliefert. Die Schlüssel sind separat zu bestellen.
Each holder is supplied with one or more screws. The keys must be ordered separately.
1.41
