Index 730 / 740
Tronçonnage
Abstechen 731 / 741
Parting off

L R

A
E L
A1
A2

L R

P P P P P P P P P P P P P P P
M M M M M M M M M M M
N N N N N N N N N N N N
S S S S S S S S S S S

TiAlN N (µk20) HN (µk10) TiAlN TiAlX N (µk20) HN (µk10) KN (µk10-20)
E A A 1 A 2 L Art. N° TiN HTA HTiN Art. N° TiN HTA HTiN KST
0.6 18° 2.5° 0.5° 3 731-0.6     741-0.6     
0.8 20° 0.3° 0.3° 5 731-0.8      741-0.8       
1.0 20° 0.3° 0.3° 5 731-1.0       741-1.0         
1.2 20° 0.3° 0.3° 5 731-1.2      741-1.2       
1.5 20° 0.3° 0.3° 7 731-1.5       741-1.5         
1.8 20° 0.3° 0.3° 7 731-1.8      741-1.8      
2.0 20° 0.3° 0.3° 7 731-2.0      741-2.0         
2.5 20° 0.3° 0.3° 7 731-2.5    741-2.5      

7XX-XX-B Sur demande pour serrage type B, voir page 1.05
Auf Anfrage für B-Spannsystem, siehe Seite 1.05
On request for B clamping system, see page 1.05
1.43
