Fonçage-tournage
GTX BB4… / BB6… Einstechen und drehen
Grooving and turning

L3

T Ø min
E1
6°
L1
10°
L2

E D
C

R L

P P P P P
M M M
N N N N
L2 L2 S S S S S
BH4… BHS4… ZTAXF
D h5 Holder Ø min L1 BHY4… BHK4… E1 T E C L3 Art. N° ZTAF ZN ZTAF ZN
BH4… 3.0 9.0 15 13.5 1.00 0.60 2.7 1.45 37 BB4R/L-3090-GT100X 
2.7
4 BHS4… 15.0 20 18.5 1.00 0.60 3.15 1.45 42 BB4R/L-30150-GT100X 
BHY4…
15
13.5
1.00
0.70
10.5
37
BB4R/L-35105-GT100X
1.6
BHK4… 3.5 17.5 20 18.5 1.00 0.70 3.15 1.6 42 BB4R/L-35175-GT100X 

L2 L2
BH6… BHS6… ZTAXF
D h5 Holder Ø min L1 BHY6… BHK6… E1 T E C L3 Art. N° ZTAF ZN ZTAF ZN
14.0 20 18.5 1.25 0.80 3.8 2.2 47 BB6R/L-40140-GT125X 
4.0
22.0 30 28.5 1.25 0.80 3.8 2.2 57 BB6R/L-40220-GT125X 
BH6… 4.5 16.0 20 18.5 1.25 0.90 4.28 2.4 47 BB6R/L-45160-GT125X 
6 BHS6… 25.0 30 28.5 1.25 0.90 4.28 2.4 57 BB6R/L-45250-GT125X 
BHY6… 17.5 20 18.5 1.25 1.00 4.75 2.5 47 BB6R/L-50175-GT125X 
BHK6… 5.0 27.5 30 28.5 1.25 1.00 4.75 2.5 57 BB6R/L-50275-GT125X 
17.5 20 18.5 1.25 1.10 5.15 2.6 47 BB6R/L-55175-GT125X 
5.5
27.5 30 28.5 1.25 1.10 5.15 2.6 57 BB6R/L-55275-GT125X 
