Fonçage-tournage
GT-ZFX BB6… Einstechen und drehen
Grooving and turning

L3

T Ø min
R E1 R
10°
L1
10°
L2

E D
10°
C
R

P P P
M M
N N
L2 L2 S S S
BH6… BHS6… ZTAXF
D Holder Ø min L1 BHY6… BHK6… E1 T E C R L3 Art. N° ZTAF ZN
14.0 20 18.5 1.25 0.80 3.8 2.2 0.08 47 BB6R-40140-GT125ZFX-R08 
4.0
22.0 30 28.5 1.25 0.80 3.8 2.2 0.08 57 BB6R-40220-GT125ZFX-R08 
16.0 20 18.5 1.25 0.90 4.28 2.4 0.08 47 BB6R-45160-GT125ZFX-R08 
4.5
25.0 30 28.5 1.25 0.90 4.28 2.4 0.08 57 BB6R-45250-GT125ZFX-R08 
BH6… 17.5 20 18.5 1.25 1.00 4.75 2.5 0.08 47 BB6R-50175-GT125ZFX-R08 
6 BHS6… 5.0 17.5 20 18.5 2.00 1.00 4.75 2.5 0.08 47 BB6R-50175-GT200ZFX-R08 
BHY6…
2.5
0.08
BB6R-50275-GT125ZFX-R08
57
28.5
30
27.5
4.75
1.00
1.25
BHK6… 27.5 30 28.5 2.00 1.00 4.75 2.5 0.08 57 BB6R-50275-GT200ZFX-R08 

17.5 20 18.5 1.25 1.10 5.15 2.6 0.08 47 BB6R-55175-GT125ZFX-R08 
17.5 20 18.5 2.00 1.10 5.15 2.6 0.08 47 BB6R-55175-GT200ZFX-R08 
5.5
27.5 30 28.5 1.25 1.10 5.15 2.6 0.08 57 BB6R-55275-GT125ZFX-R08 
27.5 30 28.5 2.00 1.10 5.15 2.6 0.08 57 BB6R-55275-GT200ZFX-R08 

12.36
