Têtes interchangeables
LW-SCM-JET ISO-Line 80° Wechselköpfe
Interchangeable heads

L
2

H
A LW

50°

B 80°

50°

Plaquettes
WSP
Inserts LW A x B H L Art. N°
LW2 10x10 5 20 LW2-SCMCN-10-0020-06-JET
CC..-0602.. LW3 12x12 6 20 LW3-SCMCN-12-0020-06-JET
LW4 16x16 8 25 LW4-SCMCN-16-0025-06-JET
LW3 12x12 6 20 LW3-SCMCN-12-0020-09-JET
CC..-09T3..
LW4 16x16 8 25 LW4-SCMCN-16-0025-09-JET

Pièces de rechange
Ersatzteile Options
Spare parts

Plaquettes
WSP
Inserts LW Art. N° Art. N° Art. N° Art. N°
LW2 LW2-U00.ER1.000
CC..-0602.. LW3 V-M2.5X7.8-T8 LW3-U00.ER1.000 C-T8
LW4 LWX-ER1.007.004 LW4-U00.ER1.000
LW3 LW3-U00.ER1.000
CC..-09T3.. V-M4X9-T15-ISO C-T15
LW4 LW4-U00.ER1.000
13.16
