Index SWITCH-Line
Têtes interchangeables
LW-SVJ-JET ISO-Line 35° Wechselköpfe
Interchangeable heads

R

L
2

H
A LW

L 52°

35°
B
C
3°

L R

Plaquettes
WSP
Inserts LW A x B H C L Art. N° Art. N°
LW2 10x10 5 5 25 LW2-SVJCL-10-0525-11-JET LW2-SVJCR-10-0525-11-JET
VC..-1103.. LW3 12x12 6 6 25 LW3-SVJCL-12-0625-11-JET LW3-SVJCR-12-0625-11-JET
LW4 16x16 8 8 25 LW4-SVJCL-16-0825-11-JET LW4-SVJCR-16-0825-11-JET
LW3 12x12 6 6 30 LW3-SVJCL-12-0630-13-JET LW3-SVJCR-12-0630-13-JET
VC..-1303..
LW4 16x16 8 8 30 LW4-SVJCL-16-0830-13-JET LW4-SVJCR-16-0830-13-JET
VC..-1604.. LW4 16x16 8 8 35 LW4-SVJCL-16-0835-16-JET LW4-SVJCR-16-0835-16-JET

Pièces de rechange
Ersatzteile Options
Spare parts

Plaquettes
WSP
Inserts LW Art. N° Art. N° Art. N° Art. N°
LW2 LW2-U00.ER1.000
VC..-1103.. LW3 V-M2.5X7.8-T8 LW3-U00.ER1.000 C-T8
LW4 LW4-U00.ER1.000
LW3 LWX-ER1.007.004 LW3-U00.ER1.000
VC..-1303.. V-M3X7.3-T8-ISO C-T15
LW4 LW4-U00.ER1.000
VC..-1604.. LW4 V-M4X9-T15-ISO LW4-U00.ER1.000 C-T15
13.20
