Index 730 / 740
Filetage
736 / 746 Gewinde drehen
Threading

L R

L
R
A E

Profil partiel
Teilprofil
Partial profile

L R

P P P P P P P P P P P P P P
M M M M M M M M M M
N N N N N N N N N N N
S S S S S S S S S S S

TiAlN N (µk20) HN (µk10) TiAlN N (µk20) HN (µk10) KN (µk10-20)
A E L R Art. N° TiN HTA HTiN Art. N° TiN HTA HTiN KST
60° 1.5 4 0 736-60-1.5    746-60-1.5     
60° 1.5 4 0.02 736-60-1.5-R02       746-60-1.5-R02       
60° 2.0 6 0 736-60-2.0    746-60-2.0     
60° 2.0 6 0.02 736-60-2.0-R02       746-60-2.0-R02      
55° 1.5 4 0 736-55-1.5    746-55-1.5   
55° 1.5 4 0.02 736-55-1.5-R02    746-55-1.5-R02   
55° 2.0 6 0 736-55-2.0    746-55-2.0   
55° 2.0 6 0.02 736-55-2.0-R02    746-55-2.0-R02   

7XX-XX-B Sur demande pour serrage type B, voir page 1.05
Auf Anfrage für B-Spannsystem, siehe Seite 1.05
On request for B clamping system, see page 1.05
1.84
