Index 730 / 740
Plaquettes à rayon
Radius Wendeplatten 737 / 747
Radius inserts

L R

R L
1°

1° 6

L R

P P P P P P
M M M M
N N N N
S S S S
TiAlN N (µk20) TiAlN N (µk20)
R L Art. N° TiN Art. N° TiN
0.25 1.5 - 747-R0.25   
0.40 2 - 747-R0.4   
0.50 2.5 737-R0.5    747-R0.5   
0.60 2.5 737-R0.6    747-R0.6   
0.75 3 737-R0.75    747-R0.75   
0.80 3 737-R0.8    747-R0.8   
1.00 4 737-R1.0    747-R1.0   

7XX-XX-B Sur demande pour serrage type B, voir page 1.05
Auf Anfrage für B-Spannsystem, siehe Seite 1.05
On request for B clamping system, see page 1.05
1.87
