TOOL RECOMMENDATIONS
ROUGHERS
T OOL REC OMMEND A TIONS PAGE R OUGHERS PAGE
Aluminum 8 ARC 3 Flute Chamfer Staggered, Bright Finish 112
Titanium 10 9 VHM 4 Flute Chamfer Staggered, AlTiN Coated 114
Stainless Steel
TABLE OF CONTENTS Inconel, High Nickel Alloys 11 END MILLS - HIGH PERFORMANCE - HEM 121
END MILLS
Brass, Bronze, Copper, Magnesium
12
13
Hardened Tool Steels
142M
Square
2 Flute
ALUMASTAR Coated
Composite Materials
14
122
2 Flute
ALUMASTAR Coated
142R
Radius
Carbon Steels, Medium Alloy Steels
15
142B
16
Cast Iron
NEW SIZES
3 Flute
A3
S, R, B
Bright Finish
116
Square
143M 2 Flute Ball ALUMASTAR Coated 124
3 Flute
ALUMASTAR Coated
125
143R 3 Flute Radius ALUMASTAR Coated 128
DRILLS - HIGH PERFORMANCE NEW SIZES V4-S 4 Flute Square AlCrN Coated 139
DRILLS
1550H 2 Flute 3xD 30° Helix AlTiN-Based Coated 23 NEW SIZES V4-R 4 Flute Radius AlCrN Coated 139
1580HD 2 Flute 3xD 30° Helix AlTiN-Based Coated 29 NEW SIZES V4-B 4 Flute Ball AlCrN Coated 139
1580H 2 Flute 3xD 30° Helix AlTiN-Based Coated 32 NEW SIZES VRX 4 Flute S, R, B AlTiN Coated 164
NEW SIZES 1580KD 2 Flute 3xD 30° Helix Coolant Fed, AlTiN-Based Coated 37 NEW SIZES V5 5 Flute S, R AlCrN Coated 152
1580KH 2 Flute 3xD 30° Helix Coolant Fed, AlTiN-Based Coated 47 NEW SIZES V5C (Chip Splitter) 5 Flute S, R AlCrN Coated 158
1250H 2 Flute 5xD 30° Helix AlTiN-Based Coated 23 NEW SIZES VRX-6 6 Flute S, R AlTiN Coated 174
1280H 2 Flute 5xD 30° Helix AlTiN-Based Coated 32 NEW SIZES VX-7 7 Flute S, R AlCrN-Based Coated 160
NEW SIZES 1280KD 2 Flute 5xD 30° Helix Coolant Fed, AlTiN-Based Coated 37 NEW SIZES VX-7C (Chip Splitter) 7 Flute S, R AlCrN-Based Coated 163
1280KH 2 Flute 5xD 30° Helix Coolant Fed, AlTiN-Based Coated 47 TMS Multi-Flute Square AlCrN Coated 132
NEW SIZES 1880KD 2 Flute 7xD 30° Helix Coolant Fed, AlTiN-Based Coated 37 TMR Multi-Flute Radius AlCrN Coated 134
1880KH 2 Flute 7xD 30° Helix Coolant Fed, AlTiN-Based Coated 47
1850H 2 Flute 12xD 30° Helix AlTiN-Based Coated 23
END MILLS - HIGH PERFORMANCE
NEW SIZES 1160 3 Flute 3xD 30° Helix ALUMASTAR Coated 17 END MILLS
1180 3 Flute 5xD 30° Helix ALUMASTAR Coated 17 242M/842M 2 Flute Square Bright Finish 177
350MX/950MX 2 Flute Ball AlTiN Coated 196
253MA/853MA 3 Flute Square AlTiN Coated 178
DRILLS 253M/853M 3 Flute Square Bright Finish 180
DRILLS - GENERAL PURPOSE
NEW SIZES 1600 2 Flute 25° Helix N/C Spotting, Bright Finish 54 253MC 3 Flute Square TiCN Coated 182
1400 2 Flute 10° Helix Combined Drill/Countersink, Bright Finish 56 263M 3 Flute Square Bright Finish 183
1500 2 Flute 3xD Straight Hard Metal, Bright Finish 57 263MC 3 Flute Square TiCN Coated 183
1500H 2 Flute 3xD Straight Hard Metal, Hardlube Coated 59 263MA/863MA 3 Flute Square AlTiN Coated 183
1510 2 Flute 3xD 15° Helix Slow Spiral, Bright Finish 61 210D 4 Flute Square DIAMOND Coated 197
NEW SIZES 1510H 2 Flute 3xD 15° Helix Slow Spiral, Hardlube Coated 64 210RD 4 Flute Radius DIAMOND Coated 198
NEW SIZES 1520 2 Flute 3xD 25° Helix Bright Finish 67 310D 4 Flute Ball DIAMOND Coated 199
NEW SIZES 1520H 2 Flute 3xD 25° Helix Hardlube Coated 73 610D 4 Flute Square DIAMOND Coated 200
1205 2 Flute 5xD 25° Helix Bright Finish 67 710D 4 Flute Ball DIAMOND Coated 201
1205H 2 Flute 5xD 25° Helix Hardlube Coated 73 H-45 4 Flute Radius AlTiN Coated 195
1200 2 Flute 5xD 25° Helix Bright Finish 83 545MA 4/5 Flute Square AlTiN Coated 192
1200H 2 Flute 5xD 25° Helix Hardlube Coated 86 545RA 4/5 Flute Radius AlTiN Coated 193
1800H 2 Flute 8xD 35° Helix Parabolic, Hardlube Coated 90 545BA 4/5 Flute Ball AlTiN Coated 194
1100 3 Flute 5xD 25° Helix Bright Finish 88 255MA/855MA 5 Flute Square AlTiN Coated 184
1100H 3 Flute 5xD 25° Helix Hardlube Coated 79 255M/855M 5 Flute Square Bright Finish 186
1120H 3 Flute 3xD 25° Helix Hardlube Coated 79 255MC 5 Flute Square TiCN Coated 188
255RA/855RA 5 Flute Radius AlTiN Coated 189
246M/846M 6 Flute Square Bright Finish 191
REAMERS
REAMERS 246MC 6 Flute Square TiCN Coated 191
4100 Standard Bright Finish 92 NEW SIZES 246MA/846MA 6 Flute Square AlTiN Coated 191
4100 Standard Metric Bright Finish 104
END
END MILLS - STUB LENGTH - GENERAL PURPOSE
MILLS

DRILL MILLS 160M/860M 2 Flute Square Bright Finish 207
DRILL MILLS
152M 2 Flute Bright Finish - Angle to a Point 106 160MA/860MA 2 Flute Square TiAlN Coated 209
152MA 2 Flute TiALN Coated - Angle to a Point 107 180M/980M 2 Flute Ball Bright Finish 214
152DA 2 Flute TiALN Coated - 120° Drill Point 110 180MA/980MA 2 Flute Ball TiAlN Coated 215
154M 4 Flute Bright Finish - Angle to a Point 108 170M/870M 4 Flute Square Bright Finish 207
154MA 4 Flute TiALN Coated - Angle to a Point 109 170MA/870MA 4 Flute Square TiAlN Coated 209
170R/870R 4 Flute Radius Bright Finish 210
170RA/870RA 4 Flute Radius TiAlN Coated 212
190M/990M 4 Flute Ball Bright Finish 214
190MA/990MA 4 Flute Ball TiAlN Coated 215
