           L’outil de référence pour le décolletage
           Hochwertiges Wendeplattensystem für Langdrehautomaten            700 Series
           Top class turning tool for automatic lathes




                                   100 % rigid !


                              Système de serrage Applitec à denture décalée
                            Applitec-Spannsystem mit verschobener Verzahnung
                               Applitec clamping system with shifted teeth






















                                       Serrage standard (A)
                                       Standard Spannsystem (A)
                                       Standard clamping system (A)













                                       Serrage type B*         ajouter -B après le numéro d’article
                                       Spannsystem Typ B*      -B nach der Artikelreferenz hinzufügen
                                       Clamping system type B*  add -B after the article number











          Changement de la plaquette possible dans la machine, sans démontage du porte-outil
          WSP-Austauschmöglichkeit in der Maschine ohne Halterausbau
          The insert can be changed in the machine without removing the tool holder

          *  = sur demande / auf Anfrage / on request                                    2.05
