Index 710 / 720
Tournage arrière
713-30° / 723-30° Rückwärts drehen
Back turning

L R

L 0.3
1°

5 0.5° E
30°
L1

L R

P P P P P P P P P P P P
M M M M M M M M
N N N N N N N N N N
S S S S S S S S

E L L 1 Art. N° TiAlN TiN N (µk20) HTA HTiN HN (µk10) Art. N° TiAlN TiN N (µk20) HTA HTiN HN (µk10)
0.8 1.6 0.85 713-30-0.8    723-30-0.8     
0.9 1.6 1.05 713-30-0.9    -
1.0 2.0 1.2 713-30-1.0       723-30-1.0     
1.1 2.0 1.4 713-30-1.1    -
1.2 2.5 1.55 713-30-1.2    723-30-1.2   
1.3 2.5 1.7 713-30-1.3    -
1.4 3.0 1.9 713-30-1.4    -
1.5 3.0 2.1 713-30-1.5       723-30-1.5   
1.8 4.0 2.6 713-30-1.8    723-30-1.8   
2.0 4.0 2.9 713-30-2.0       723-30-2.0   

1.28
