TOP-Line Main Menu Index TOP-Line End Index
Index 710 / 720
Tournage arrière
713-60° / 723-60° Rückwärts drehen
Back turning

L R

L 0.3
1°

5 60° 0.5° E
L1

L R

P P P P P P
M M M M
N N N N
S S S S

E L L 1 Art. N° TiAlN TiN N (µk20) Art. N° TiAlN TiN N (µk20)
0.8 1.6 0.3 713-60-0.8    723-60-0.8   
0.9 1.6 0.35 713-60-0.9    -
1.0 2.0 0.4 713-60-1.0    723-60-1.0  
1.1 2.0 0.45 713-60-1.1    -
1.2 2.5 0.5 713-60-1.2    723-60-1.2  
1.3 2.5 0.6 713-60-1.3    -
1.4 3.0 0.65 713-60-1.4    -
1.5 3.0 0.7 713-60-1.5    723-60-1.5   
1.8 4.0 0.9 713-60-1.8    723-60-1.8  
2.0 4.0 1.0 713-60-2.0    723-60-2.0   

1.30
