Index 710 / 720
Tournage arrière
Rückwärts drehen 713-45° / 723-45°
Back turning

L R

L 0.3
1°

5 45° 0.5° E
L1

L R

P P P P P P P P P P P P
M M M M M M M M
N N N N N N N N N N
S S S S S S S S

E L L 1 Art. N° TiAlN TiN N (µk20) HTA HTiN HN (µk10) Art. N° TiAlN TiN N (µk20) HTA HTiN HN (µk10)
0.8 1.6 0.5 713-45-0.8      723-45-0.8   
0.9 1.6 0.6 713-45-0.9    -
1.0 2.0 0.7 713-45-1.0      723-45-1.0  
1.1 2.0 0.8 713-45-1.1    -
1.2 2.5 0.9 713-45-1.2    723-45-1.2   
1.3 2.5 1.0 713-45-1.3    -
1.4 3.0 1.1 713-45-1.4    -
1.5 3.0 1.2 713-45-1.5       723-45-1.5   
1.8 4.0 1.5 713-45-1.8    723-45-1.8  
2.0 4.0 1.7 713-45-2.0    723-45-2.0   

1.29
