Plaquettes de gorge pour circlips
Einstechwendeplatte für Seegerring GX
Grooving inserts for retaining ring

6°

R
L
E

0.5°
0.5°
R L

L R

E
P P
M M
N N N N
S S S S

E ±0.01 L R Art. N° HTA HN (µk10) Art. N° HTA HN (µk10)
0.26 0.8 0.03 T216L-GX026   T216R-GX026  
0.36 0.8 0.03 T216L-GX036   T216R-GX036  
0.46 0.8 0.03 T216L-GX046   T216R-GX046  
0.50 1.5 0.03 T216L-GX050   T216R-GX050  
Selon DIN6799 et DIN471 0.57 1.5 0.03 T216L-GX057   T216R-GX057  
Gemäss DIN6799 und DIN471 0.67 1.5 0.03 T216L-GX067   T216R-GX067  
According to DIN6799 and DIN471 0.77 2.0 0.03 T216L-GX077   T216R-GX077  
0.87 2.0 0.03 T216L-GX087   T216R-GX087  
0.97 2.5 0.03 T216L-GX097   T216R-GX097  
1.00 2.5 0.03 T216L-GX100   T216R-GX100  
1.10 2.5 0.03 T216L-GX110   T216R-GX110  
1.20 2.5 0.03 T216L-GX120   T216R-GX120  
1.30 2.5 0.03 T216L-GX130   T216R-GX130  
1.50 2.5 0.03 T216L-GX150   T216R-GX150  
1.60 2.5 0.03 T216L-GX160   T216R-GX160  
1.85 2.5 0.03 T216L-GX185   T216R-GX185  
2.00 2.5 0.03 T216L-GX200   T216R-GX200  
2.50 2.5 0.03 T216L-GX250   T216R-GX250  
7.09
