Fonçage-tournage avec coupe positive
GTX Einstechen und drehen mit positivem Spanwinkel
Grooving and turning with positive cut

10°

R
L
E

0.5°
0.5°

R L
6°

L R

P P
M M
N N N N
S S S S

E L R Art. N° HTA HN (µk10) Art. N° HTA HN (µk10)
1.0 2.5 0.03 T216L-GTX100   T216R-GTX100  
1.0 2.5 0.08 T216L-GTX100-R08   T216R-GTX100-R08  
1.5 2.5 0.03 T216L-GTX150   T216R-GTX150  
1.5 2.5 0.08 T216L-GTX150-R08   T216R-GTX150-R08  
1.5 2.5 0.15 T216L-GTX150-R15   T216R-GTX150-R15  
2.0 2.5 0.03 T216L-GTX200   T216R-GTX200  
2.0 2.5 0.08 T216L-GTX200-R08   T216R-GTX200-R08  
2.0 2.5 0.15 T216L-GTX200-R15   T216R-GTX200-R15  
2.5 2.5 0.15 T216L-GTX250-R15   T216R-GTX250-R15  

7.12
