Paramètres de coupe indicatifs
Empfohlene Schnittwerte
Standard machining data

Inox
Rostfreistahl
Stahl
Steel
ISO-Line P Acier M Stainless steel
G tolerance class Tough grade, for normal to difficult machining conditions Wear resistant grade, for finishing and light machining Acier de décolletage Acier faiblement allié Acier fortement allié Austénitique Martensitique
Leicht legierter Stahl
Hochlegierter Stahl
Martensitisch
Austenitisch
Automatenstahl
Low alloyed steel
High alloyed steel
Free-cutting steel
Martensitic
Austenitic
50-120
60-140
K20 HTA VC (m/min) F (mm/U) VC (m/min) F (mm/U) VC (m/min) F (mm/U) VC (m/min) F (mm/U) VC (m/min) F (mm/U)
0.01-0.12
0.01-0.10
0.01-0.12
60-150
60-140
0.01-0.08
0.01-0.12
80-180
FN-X8 TiAlX HTAX 80-180 0.01-0.12 60-150 0.01-0.10 50-120 0.01-0.08 60-140 0.01-0.12 60-140 0.01-0.12
TiN 80-170 0.01-0.12 60-140 0.01-0.10 60-120 0.01-0.12 60-120 0.01-0.12
K20 K10
TiAlN 80-180 0.03-0.15 60-160 0.03-0.12 50-120 0.03-0.10 60-140 0.03-0.12 60-140 0.03-0.15
ENP-X8 TiN 80-170 0.03-0.15 60-150 0.03-0.12 60-120 0.03-0.12 60-120 0.03-0.15
K20
TiAlN 80-180 0.01-0.12 60-150 0.01-0.10 60-140 0.01-0.15 60-140 0.01-0.15
TiAlX 80-180 0.01-0.12 60-150 0.01-0.10 50-120 0.01-0.08 60-140 0.01-0.12 60-140 0.01-0.12
FN-X17 ST HST 80-180 0,01-0,12 60-150 0,01-0,10 50-120 0,01-0,08 60-150 0,01-0,12 60-150 0,01-0,12
TiN 80-170 0.01-0.12 60-120 0.01-0.15 60-120 0.01-0.15
K20 K10
TiAlN HTA 80-180 0.03-0.15 60-160 0.03-0.12 50-120 0.03-0.10 60-140 0.03-0.15 60-140 0.03-0.18
ST 80-180 0,01-0,12 60-150 0,01-0,10 50-120 0,01-0,08 60-150 0,01-0,12 60-150 0,01-0,12
ENP-X17 TiAlX HTAX 80-180 0.01-0.12 60-150 0.01-0.10 50-120 0.01-0.08 60-140 0.01-0.12 60-140 0.01-0.12
TiN 80-170 0.03-0.15 60-150 0.03-0.12 60-120 0.01-0.15 60-120 0.03-0.18
K20 K10
TiAlN HTA 60-140 0.01-0.12
FN-X25 TiN 60-120 0.01-0.12
K20 K10
TiAlN 60-140 0.03-0.12 60-140 0.03-0.15
ENP-X25 TiAlX 80-180 0.01-0.12 60-150 0.01-0.10 50-120 0.01-0.08 60-140 0.01-0.12 60-140 0.01-0.12
TiN 60-120 0.03-0.12 60-120 0.03-0.15
K20
ENP-X20 ZTA 60-140 0.03-0.18 60-140 0.03-0.18
HTiX 60-140 0.03-0.18 60-140 0.03-0.18
G tolerance class
Special 35° VC..-11
TiAlN HTA 80-180 0.01-0.12 60-150 0.01-0.10 50-120 0.01-0.08 60-140 0.01-0.12 60-140 0.01-0.12
TiAlX HTAX 80-180 0.01-0.12 60-150 0.01-0.10 50-120 0.01-0.08 60-140 0.01-0.12 60-140 0.01-0.12
FL / FR-X10 ST HST 80-180 0,03-0,15 60-160 0,03-0,12 50-120 0,03-0,10 60-150 0,03-0,12 60-150 0,01-0,12
TiN 80-170 0.01-0.12 60-140 0.01-0.10 60-120 0.01-0.12 60-120 0.01-0.12
K20 K10
TiAlN HTA 80-180 0.03-0.15 60-160 0.03-0.12 50-120 0.03-0.10 60-140 0.03-0.12 60-140 0.03-0.15
TiAlX HTAX 80-180 0.03-0.15 60-160 0.03-0.12 50-120 0.03-0.10 60-140 0.03-0.12 60-140 0.03-0.15
ELP/ERP-X10 ST 80-180 0,03-0,15 60-160 0,03-0,12 50-120 0,03-0,10 60-150 0,03-0,12 60-150 0,01-0,12
TiN 80-170 0.03-0.15 60-150 0.03-0.12 60-120 0.03-0.12 60-120 0.03-0.15
K20 K10
HTA 80-180 0.01-0.10 60-150 0.01-0.10 60-140 0.01-0.10 60-140 0.01-0.10
FN-K18 HTiN 80-170 0.01-0.10 60-140 0.01-0.10 60-120 0.01-0.10 60-120 0.01-0.10
K10
HTA 80-150 0.01-0.10
FN-0 HTiN 80-140 0.01-0.10
K10
