Paramètres de coupe indicatifs
Empfohlene Schnittwerte
Standard machining data

Inox
Stahl
Rostfreistahl
Steel
ISO-Line P Acier M Stainless steel
M tolerance class Tough grade, for normal to difficult machining conditions Wear resistant grade, for finishing and light machining Acier de décolletage Acier faiblement allié Acier fortement allié Austénitique Martensitique
Hochlegierter Stahl
Austenitisch
Leicht legierter Stahl
Automatenstahl
Martensitisch
Martensitic
Low alloyed steel
Free-cutting steel
Austenitic
High alloyed steel
EN-XF3 TAC HTAC VC (m/min) F (mm/U) VC (m/min) F (mm/U) VC (m/min) F (mm/U) VC (m/min) F (mm/U) VC (m/min) F (mm/U)
0.03-0.15
60-140
100-200
50-120
0.03-0.15
0.03-0.12
80-160
60-140
0.03-0.12
0.03-0.10
EN-XF2 TAC HTAC 100-200 0.03-0.15 80-160 0.03-0.12 50-120 0.03-0.10 60-140 0.03-0.12 60-140 0.03-0.15
HTi5 100-250 0.03-0.15 80-220 0.03-0.12 50-180 0.03-0.10 80-200 0.03-0.12 80-200 0.03-0.15
EN-MF2 TAC HTAC 100-200 0.04-0.15 80-160 0.04-0.12 50-120 0.04-0.10 60-140 0.04-0.12 60-140 0.04-0.15
Ti5 HTi5 100-250 0.04-0.15 80-220 0.04-0.12 50-180 0.04-0.10 80-200 0.04-0.12 80-200 0.04-0.15
Tmax 100-220 0.04-0.30 80-180 0.04-0.25 50-150 0.04-0.20 60-150 0.04-0.25 60-150 0.04-0.25
EN-MF Ti4 100-250 0.05-0.30 80-220 0.05-0.25 50-180 0.05-0.20 80-200 0.05-0.25 80-200 0.05-0.25
Ti7 60-150 0.05-0.20 60-150 0.05-0.20
EN-HF3 TiX HTiX 100-220 0.06-0.35 80-180 0.06-0.30 50-150 0.06-0.25 60-150 0.06-0.25 60-150 0.06-0.25
Ti6 100-250 0.06-0.35 80-220 0.06-0.30 50-180 0.06-0.25 80-200 0.06-0.25 80-200 0.06-0.25
Tmax 100-220 0.08-0.40 80-180 0.08-0.35 50-150 0.08-0.30 60-150 0.08-0.30 60-150 0.08-0.30
EN-HF TAC 100-200 0.08-0.40 80-160 0.08-0.35 50-140 0.08-0.30 60-140 0.08-0.30 60-140 0.08-0.30
Ti4 100-250 0.08-0.40 80-220 0.08-0.35 50-180 0.08-0.30 80-200 0.08-0.30 80-200 0.08-0.30
Ti5 HTi5 100-280 0.08-0.40 80-250 0.08-0.35 50-200 0.08-0.30 80-220 0.08-0.30 80-220 0.08-0.30
ISO-Line
CERMET
FN-X8 CTA 100-350 0.01-0.12 80-300 0.01-0.10 70-250 0.01-0.08 80-250 0.01-0.12 80-250 0.01-0.12
CERMET CN6 100-300 0.01-0.12 80-250 0.01-0.10 70-200 0.01-0.08
ENP-KX CT7 HCT7 100-350 0.03-0.20 80-300 0.03-0.18 70-250 0.03-0.15 80-250 0.03-0.18 80-250 0.03-0.18
CERMET CN6 100-300 0.03-0.20 80-250 0.03-0.18 70-200 0.03-0.15
EN-KM CT7 HCT7 100-350 0.03-0.25 80-300 0.03-0.20 70-250 0.03-0.18 80-250 0.03-0.20 80-250 0.03-0.20
CERMET CN6 100-300 0.03-0.25 80-250 0.03-0.20 70-200 0.03-0.18

9.18
