Têtes interchangeables
Wechselköpfe ISO-Line 55° LW-SDN-JET
Interchangeable heads
L
2
H
A LW
62.5°
55°
B
62.5°
Plaquettes
WSP
Inserts LW A x B H L Art. N°
LW3 12x12 6 20 LW3-SDNCN-12-0020-07-JET
DC..-0702
LW4 16x16 8 25 LW4-SDNCN-16-0025-07-JET
LW3 12x12 6 25 LW3-SDNCN-12-0025-11-JET
DC..-11T3
LW4 16x16 8 25 LW4-SDNCN-16-0025-11-JET
Plaquettes
WSP
Pièces de
Inserts LW Art. N° Art. N° Art. N° Art. N°
rechange
Ersatzteile
Spare parts DC..-0702 LW3 V-M2.5X7.8-T8 C-T8 LW3-U00.ER1.000
LW4 LW4-U00.ER1.000
LWX-ER1.007.002
LW3 LW3-U00.ER1.000
DC..-11T3 V-M4X9-T15-ISO C-T15
LW4 LW4-U00.ER1.000
11.15
