Plaquettes en métal dur
VCGT-L/R-X10 35° VHM-Wendeplatten
Solid carbide inserts

non revêtu
VCGT PVD unbeschichtet
uncoated
FL / FR-X10 P P P P P P P
M M M M M M M
N N N N N
S S S S S S S S
R Art. N° ST TiAlN HTA TiAlX HTAX TiN HST K10 K20
0.03 VCGT-1103003-FL-X10       
L 0.08 VCGT-1103008-FL-X10       
0.1 VCGT-110301-FL-X10       
R 0.2 VCGT-110302-FL-X10       
0.03 VCGT-1103003-FR-X10         
7 5.5 0.08 VCGT-1103008-FR-X10         
R 0.1 VCGT-110301-FR-X10         
35° 0.2 VCGT-110302-FR-X10         
1.35
86°

non revêtu
VCGT PVD unbeschichtet
uncoated
ELP/ERP-X10 P P P P P P
M M M M M M
N N N N N
S S S S S

R Art. N° ST TiAlN HTA TiAlX HTAX TiN K10 K20
0.03 VCGT-1103003-ELP-X10      
L 0.08 VCGT-1103008-ELP-X10      
0.1 VCGT-110301-ELP-X10      
R 0.2 VCGT-110302-ELP-X10      
0.03 VCGT-1103003-ERP-X10        
7 5.5 0.08 VCGT-1103008-ERP-X10        
R 0.1 VCGT-110301-ERP-X10        
35° 0.2 VCGT-110302-ERP-X10        
1.35
86°

9.62
