Plaquettes en métal dur
VCGT-X8 35° VHM-Wendeplatten
Solid carbide inserts

non revêtu
VCGT PVD unbeschichtet
uncoated
FN-X8 P P P P P
M M M M M
N N N N N
S S S S S S
R Art. N° TiAlN TiAlX TiN HTA HTAX K20 K10
0.05 VCGT-1103005-FN-X8       
~11 R 0.08 VCGT-1103008-FN-X8      
0.1 VCGT-110301-FN-X8       
0.15 VCGT-1103015-FN-X8      
0.2 VCGT-110302-FN-X8       
0.4 VCGT-110304-FN-X8       
~13 R 0.05 VCGT-1303005-FN-X8     
0.1 VCGT-130301-FN-X8     
0.2 VCGT-130302-FN-X8     
0.4 VCGT-130304-FN-X8     
~16 R 0.05 VCGT-1604005-FN-X8     
0.1 VCGT-160401-FN-X8     
0.2 VCGT-160402-FN-X8     
0.4 VCGT-160404-FN-X8     

non revêtu
VCGT PVD unbeschichtet
uncoated
ENP-X8 P P
M M
N N N
S
TiAlN
R Art. N° TiN K20
0.05 VCGT-1103005-ENP-X8   
~11 R 0.08 VCGT-1103008-ENP-X8  
0.1 VCGT-110301-ENP-X8   
0.15 VCGT-1103015-ENP-X8  
0.2 VCGT-110302-ENP-X8   
0.4 VCGT-110304-ENP-X8   
~13 R 0.05 VCGT-1303005-ENP-X8  
0.1 VCGT-130301-ENP-X8  
0.2 VCGT-130302-ENP-X8  
0.4 VCGT-130304-ENP-X8  
~16 R 0.05 VCGT-1604005-ENP-X8   
0.1 VCGT-160401-ENP-X8   
0.2 VCGT-160402-ENP-X8   
0.4 VCGT-160404-ENP-X8   

9.64
