Plaquettes en métal dur
VHM-Wendeplatten 35° VCGT-X17
Solid carbide inserts

non revêtu
VCGT PVD unbeschichtet
uncoated
FN-X17 P P P P P P
M M M M M M
N N N N N N
S S S S S S S S
R Art. N° ST TiAlN TiN HST HTA HTAX K20 K10
0.05 VCGT-1103005-FN-X17        
~11 R 0.08 VCGT-1103008-FN-X17       
0.1 VCGT-110301-FN-X17        
0.15 VCGT-1103015-FN-X17       
0.2 VCGT-110302-FN-X17        
0.4 VCGT-110304-FN-X17        
~13 R 0.05 VCGT-1303005-FN-X17       
0.1 VCGT-130301-FN-X17       
0.2 VCGT-130302-FN-X17       
0.4 VCGT-130304-FN-X17       
~16 R 0.05 VCGT-1604005-FN-X17       
0.1 VCGT-160401-FN-X17       
0.2 VCGT-160402-FN-X17       
0.4 VCGT-160404-FN-X17       
0.8 VCGT-160408-FN-X17       

non revêtu
VCGT PVD unbeschichtet
uncoated
ENP-X17 P P P
M M M
N N N
S S

R Art. N° ST TiAlN TiN K20
0.05 VCGT-1103005-ENP-X17    
~11 R 0.08 VCGT-1103008-ENP-X17   
0.1 VCGT-110301-ENP-X17    
0.15 VCGT-1103015-ENP-X17   
0.2 VCGT-110302-ENP-X17    
0.4 VCGT-110304-ENP-X17    
~13 R 0.05 VCGT-1303005-ENP-X17   
0.1 VCGT-130301-ENP-X17   
0.2 VCGT-130302-ENP-X17   
0.4 VCGT-130304-ENP-X17   
0.05 VCGT-1604005-ENP-X17    
~16 R 0.1 VCGT-160401-ENP-X17    
0.2 VCGT-160402-ENP-X17    
0.4 VCGT-160404-ENP-X17    
0.8 VCGT-160408-ENP-X17    
9.65
