Porte-outils à serrage hydraulique
Hydro-Dehnspann-System Halter BHY6-D
Holders with hydraulic clamping system
L1
L2
B
D L3 Ø 30
A d M8x1 22.9
22.9
d Bars D L1 L2 L3 A x B Art. N°
12 90 60 55 11.2x11.2 BHY6-D12-90-F4
16 90 60 55 14.5x14.5 BHY6-D16-90-F4
x
7
.
1
6 BB6… 1 9 20 0 5 9 90 0 6 60 0 5 55 5 1 18x18 7 BHY6-D19.05-90-F4
BF6…
BHY6-D20-90-F4
22 90 60 55 20x20 BHY6-D22-90-F4
25 100 70 65 23x23 BHY6-D25-100-F4
Pièces de rechange
Ersatzteile
Spare parts
Art. N° Art. N°
BHY6… J-M8X1-D6 C-6P-3.0
more option
see JET-Line
12.17
