Porte-outils coudés
BHK4N Kröpfhalter
Cranked holders

A1 A
A/2

130
30.5
x-x x

M8x1
d
H
L3

F B
x
5.5
18.5

d Bars L3 A x B F H A1 Art. N°
8x8 8.5 37 12 BHK4N-0808X-32R
10x10 8.5 37 12 BHK4N-1010X-32R
32
12x12 8.5 37 12 BHK4N-1212X-32R
16x16 8.5 37 16 BHK4N-1616X-32R
8x8 13.5 42 12 BHK4N-0808X-37R
4 BB4R… 37 10x10 13.5 42 12 BHK4N-1010X-37R
BF4R…
12x12 13.5 42 12 BHK4N-1212X-37R
16x16 13.5 42 16 BHK4N-1616X-37R
10x10 18.5 47 12 BHK4N-1010X-42R
42 12x12 18.5 47 12 BHK4N-1212X-42R
16x16 18.5 47 16 BHK4N-1616X-42R

Pièces de rechange
Ersatzteile Option
Spare parts
Art. N° Art. N° Art. N° Art. N°
BHK4N… V-BHK-M4X0.5-T8 BHK4N… C-T8 J-M8X1-D6 SET-NM1.2-TX8
more option
see JET-Line
12.18
