Porte-outils coudés
Kröpfhalter BHK6N
Cranked holders

A1 A
A/2

130
30.5

x-x x
M8x1

d
H
L3

F
B
x
6
18.5

d Bars L3 A x B F H A1 Art. N°
10x10 18.5 52.5 12 BHK6N-1010X-47R
47 12x12 18.5 52.5 12 BHK6N-1212X-47R
18.5
16x16
6 BB6R… 10x10 28.5 52.5 16 BHK6N-1616X-47R
62.5
BF6R…
BHK6N-1010X-57R
12
57 12x12 28.5 62.5 12 BHK6N-1212X-57R
16x16 28.5 62.5 16 BHK6N-1616X-57R

Pièces de rechange
Ersatzteile Option
Spare parts
Art. N° Art. N° Art. N° Art. N°
BHK6N… V-BHK-M4X0.5-T8 BHK6N… C-T8 J-M8X1-D6 SET-NM1.2-TX8
more option
see JET-Line
12.19
