Index 730 / 740
Fonçage-tournage
Einstechen und drehen 734 / 744
Grooving and turning

L R

E L
R
0.3°

R 6

L R

P P P P P P P P P P P P P P P P
M M M M M M M M M M M M
N N N N N N N N N N N N
S S S S S S S S S S S S

E L R Art. N° TiAlN TiN N (µk20) HTA HTiN HN (µk10) Art. N° TiAlN TiAlX TiN N (µk20) HTA HTAX HTiN HN (µk10) KST KN (µk10-20)
0.5 1.5 0 734-0.5      744-0.5          
0.6 1.8 0 734-0.6      744-0.6          
0.75 2 0 734-0.75    744-0.75          
0.8 2 0 734-0.8      744-0.8          
0.8 2 0.08 - 744-0.8-R08         
0.9 2.5 0 - 744-0.9       
0.95 3 0 734-0.95    744-0.95       
1.0 2.5 0 734-1.0       744-1.0          
1.0 2.5 0.08 734-1.0-R08       744-1.0-R08       
1.2 3 0 734-1.2      744-1.2        
1.5 3 0 734-1.5       744-1.5          
1.5 3 0.08 734-1.5-R08      744-1.5-R08          
1.5 3 0.15 - 744-1.5-R15      
1.5 3 0.20 - 744-1.5-R20       
1.8 4 0 734-1.8      744-1.8       
2.0 4 0 734-2.0      744-2.0       
2.0 4 0.08 734-2.0-R08      744-2.0-R08       
2.0 4 0.15 - 744-2.0-R15      
2.0 4 0.20 - 744-2.0-R20       
2.5 6 0 734-2.5    744-2.5       
