Index 730 / 740
Fonçage-tournage
Einstechen und drehen 734X / 744X
Grooving and turning

L R
10°

E L
R
0.3°

R 6

L R

P P P P P P P P P P P P P P P P P
M M M M M M M M M M M M M
N N N N N N N N N N N N N
S S S S S S S S S S S S S

TiAlN N (µk20) HTiN HN (µk10) TiAlN TiAlX N (µk20) HTAX HTiN HN (µk10) KN (µk10-20)
E L R Art. N° TiN HTA Art. N° ST TiN HTA KST
0.5 2 0 744X-0.5  
0.8 2 0 734X-0.8      744X-0.8          
1.0 2.5 0 734X-1.0      744X-1.0          
1.0 2.5 0.08 734X-1.0-R08      744X-1.0-R08          
1.2 3 0 734X-1.2      744X-1.2         
1.5 3 0 734X-1.5       744X-1.5          
1.5 3 0.08 734X-1.5-R08      744X-1.5-R08          
1.5 3 0.15 - 744X-1.5-R15         
1.5 3 0.20 - 744X-1.5-R20        
1.8 4 0 734X-1.8    744X-1.8       
2.0 4 0 734X-2.0      744X-2.0          
2.0 4 0.08 734X-2.0-R08      744X-2.0-R08         
2.0 4 0.15 - 744X-2.0-R15        
2.0 4 0.20 734X-2.0-R20       744X-2.0-R20          
2.5 6 0 734X-2.5      744X-2.5        

7XX-XX-B Sur demande pour serrage type B, voir page 1.05
Auf Anfrage für B-Spannsystem, siehe Seite 1.05
On request for B clamping system, see page 1.05
1.77
