Directorio - Calibres de control NANO para micromecánica y relojeria
Directory - Thread gauges NANO for micromechanics and watchmaking

Calibres tampon Calibres anillos Contra calibres
Thread plug gauges Thread ring gauges Plug check gauges

Tipo
Type
DN01 GO DN01 GO DN02 NO-GO DZ04 GO DZ14 NOªGO DN04 GO DN14 NOªGO RN05ª1 GO RN15ª1 GO RN05ª2 NOªGO RN15ª2 NOªGO

Características
Characteristics

M 4H / 5h ISO DIN 14 158 158 164 164 169 169 174 174 179 179
ISO DIN 13
M 6H / 6g ISO DIN 13 158 158 164 164 169 169 174 174 179 179

M 5H / 6h ISO DIN 13 158 158 164 164 169 169 174 174 179 179
MF 4H / 4h ISO DIN 13 159 159 165 165 170 170
MF 6H / 6g ISO DIN 13 159 159 165 165 170 170 175 175 180 180
MF 6h ISO DIN 13 165 165 170 170 175 175 180 180
UNC 2B / 2A ASME B1.1 160 160 166 166 171 171 176 176 181 181
UNC 3B / 3A ASME B1.1 160 160 166 166 171 171 176 176 181 181
UNF 2B / 2A ASME B1.1 160 160 166 166 171 171 176 176 181 181

UNF 3B / 3A ASME B1.1 160 160 166 166 171 171 176 176 181 181
S NIHS 3G NIHS 161
S NIHS 4H NIHS 161
S NIHS 4H / 3G NIHS 161
S NIHS NIHS 167 167 172 172 177 177 182 182
S NIHS NT NIHS 162 162 167 167 172 172 177 177 182 182
SF NIHS 3G NIHS 163
SF NIHS 4H NIHS 163
SF NIHS 4H / 3G NIHS 163

SF NIHS NIHS 168 168 173 173 178 178 183 183
SF NIHS NT NIHS 178 178 183 183
SL SL 15-01 163 163
