M ISO DIN 13 VHM < 3µm DC h6
CAR
GWi GWi3067VS GWi3067VX
GWi3067VS VS
R10
GWi3067VX VX
R10
d 2 d 3
d 1
l
3 l
1 P
3 x D 1 3 x D 1
Ø D 1 P d 1 l 1 l 3 d h6 d 3 ID ID
2
M mm mm mm mm mm mm
1.4 0.3 1.06 40 4.6 4 0.64 3 1.1 l 186443 l 187453
1.6 0.35 1.2 40 5.3 4 0.71 3 1.25 l 186444 l 187454
1.8 0.35 1.4 40 5.9 4 0.91 3 1.45 l 186445 l 187455
2 0.4 1.54 40 6.6 4 0.98 3 1.6 l 186446 l 187456
2.3 0.4 1.84 40 7.5 4 1.28 3 1.9 l 194327 l 194337
2.5 0.45 1.98 40 8.1 4 1.35 3 2.05 l 186447 l 187457
2.6 0.45 2.08 40 8.4 4 1.45 3 2.15 l 194328 l 194338
3 0.5 2.43 51 9.9 5 1.73 4 2.5 l 186448 l 187458
3.5 0.6 2.81 51 11.6 6 1.97 4 2.9 l 186449 l 187459
4 0.7 3.2 51 13.3 6 2.22 4 3.3 l 186450 l 187460
5 0.8 4.08 51 16.5 8 2.96 4 4.2 l 186451 l 187461
6 1 4.85 51 19.8 8 3.45 4 5 l 186452 l 187462
8 1.25 5.95 75 27 6 4.2 5 6.8 l 186453 l 187463
10 1.5 7.95 83 33 8 5.85 5 8.5 l 186454 l 187464
12 1.75 9.95 95 40 10 7.5 5 10.2 l 186455 l 187465
14 2 10.95 120 52 12 8.15 5 12 l 186456 l 187466
16 2 10.95 120 52 12 8.15 5 14 l 186825 l 187467
18 2.5 13.95 135 65 14 10.45 6 15.5 l 186457 l 187468
20 2.5 13.95 135 65 14 10.45 6 17.5 l 186826 l 187469
