VHM h6
MF ISO DIN 13 CAR < 3µm DC
GWi GWi3066VS GWi3066VX
GWi3066VS VS
R10
GWi3066VX VX
R10
d 2 d 3
d 1
l
3 l
1 P
2.5 x D 1 2.5 x D 1
Ø D 1 P d 1 l 1 l 3 d h6 d 3 ID ID
2
MF mm mm mm mm mm mm
2 0.2 1.77 40 5.3 4 1.49 3 1.8 l 186086 l 187346
2 0.25 1.71 40 5.4 4 1.36 3 1.75 l 186087 l 187347
2.5 0.2 2.27 40 6.6 4 1.99 3 2.3 l 186088 l 187348
2.5 0.25 2.21 40 6.6 4 1.86 3 2.25 l 186089 l 187349
3 0.35 2.6 51 8.2 5 2.11 4 2.65 l 186090 l 187350
4 0.5 3.43 51 10.9 6 2.73 4 3.5 l 186091 l 187351
5 0.5 4.43 51 13.4 8 3.73 4 4.5 l 186092 l 187352
6 0.75 4.95 51 16.4 8 3.9 4 5.25 l 186093 l 187353
8 1 5.95 75 22 6 4.55 5 7 l 186094 l 187354
10 1 7.95 83 27 8 6.55 5 9 l 186095 l 187355
10 1.25 7.95 83 28 8 6.2 5 8.8 l 186096 l 187356
12 1.5 9.95 95 33 10 7.85 5 10.5 l 186097 l 187357
14 1.5 10.95 120 43 12 8.85 5 12.5 l 186098 l 187358
16 1.5 10.95 120 43 12 8.85 5 14.5 l 186819 l 187359
18 1.5 13.95 135 53 14 11.85 6 16.5 l 186099 l 187360
20 1.5 13.95 135 53 14 11.85 6 18.5 l 186820 l 187361
