DIXI 7240-xD Z = 2

FRESAS FRONTALES EXTRA CORTAS P.198
MANGO REFORZADO
D L D D L L DIXI CARBURO TiAlN
1 1 2 h5 2
Ø<2.00 - 0/-0.01
Ø<3.00 - 0/-0.02
Ø≥3.00 - e8
1.95 7240-3D 66078 66159
3.25 7240-5D 66206 66261
5.20 7240-8D 66301 66367
0.65 0.65 0.60 3 38
6.50 7240-10D 979334 979375
7.80 7240-12D 979417 979450
9.75 7240-15D 979482 979500
2.10 7240-3D 66079 66160
3.50 7240-5D 66207 66262
5.60 7240-8D 66302 66368
0.70 0.70 0.65 3 38
7.00 7240-10D 979335 979376
8.40 7240-12D 979419 979451
10.50 7240-15D 979483 979503
2.25 7240-3D 66080 66161
3.75 7240-5D 66208 66263
6.00 7240-8D 66303 66369
0.75 0.75 0.70 3 38
7.50 7240-10D 979336 979377
9.00 7240-12D 979420 979452
11.25 7240-15D 979484 979505
2.40 7240-3D 66081 66162
4.00 7240-5D 66209 66264
6.40 7240-8D 66304 66370
0.80 0.80 0.75 3 38
8.00 7240-10D 979337 979378
9.60 7240-12D 979421 979453
12.00 7240-15D 979485 979506
2.55 7240-3D 66082 66164
4.25 7240-5D 66210 66265
6.80 7240-8D 66305 66371
0.85 0.85 0.80 3 38
8.50 7240-10D 979338 979409
10.20 7240-12D 979423 979454
12.75 7240-15D 979486 979507
2.70 7240-3D 66083 66165
4.50 7240-5D 66211 66266
7.20 7240-8D 66306 66372
0.90 0.90 0.85 3 38
9.00 7240-10D 979339 979379
10.80 7240-12D 979430 979455
13.50 7240-15D 979487 979509
2.85 7240-3D 66084 66166
4.75 7240-5D 66212 66267
7.60 7240-8D 66307 66373
0.95 0.95 0.90 3 38
9.50 7240-10D 979340 979380
11.40 7240-12D 979431 979456
14.25 7240-15D 979488 979510
3.00 7240-3D 66110 66167
5.00 7240-5D 66213 66268
8.00 7240-8D 66308 66374
1.00 1.00 0.95 3 38
10.00 7240-10D 979341 979381
12.00 7240-12D 979206 979457
15.00 7240-15D 979489 979511
3.15 7240-3D 66113 66168
5.25 7240-5D 66214 66269
8.40 7240-8D 66309 66375
1.05 1.05 1.00 3 38
10.50 7240-10D 979342 979382
12.60 7240-12D 979432 979458
15.75 7240-15D 979490 979512
3.30 7240-3D 66115 66169
5.50 7240-5D 66218 66270
8.80 7240-8D 66310 66376
1.10 1.10 1.05 3 38
11.00 7240-10D 979343 979383
13.20 7240-12D 979433 979459
16.50 7240-15D 979491 979513
