P. 801
High feed end mills
Inserts 10mm, integral air/cooling channel
High feed end mills Delivery range: Cutter body incl. clamping screws for inserts
Order-N°. d 1 d 2 d 3 l 7 ap max. z I
W02200253 25.00 12.50 21.00 35 1.00 3 17 M12 •
VI
Accessories Delivery range clamping screws for inserts: Packaging unit 10 pieces
Order-N°.
W90110013 Torque screwdriver 3.2 Nm with blade Torx TX 15 •
W90111013 Interchangeable blade for torque screwdriver TX 15 •
W90100013 Screwdriver Torx TX 15 •
W90500013 Clamping screws for inserts Torx TX 15 / M3.5 x 7.2 •
fraisa.com
799
