Face milling cutter 45°
Inserts 13mm, integral air/cooling channel
Face milling cutter 45° Delivery range: Cutter body incl. clamping screws for inserts
Order-N°. d 1 d 2 d 3 b ap max. z
W01410403 40.00 16.00 54.00 40.0 6.00 3 •
W01410504 50.00 22.00 63.90 40.0 6.00 4 •
W01410635 63.00 22.00 76.90 40.0 6.00 5 •
W01410806 80.00 27.00 93.90 50.0 6.00 6 •
W01410100 100.00 32.00 113.90 50.0 6.00 7 •
W01410125 125.00 40.00 138.90 63.0 6.00 8 •
VI
Accessories Delivery range clamping screws for inserts: Packaging unit 10 pieces
Order-N°.
W91110013 Torque screwdriver 5.0 Nm with blade Torx TX 20 •
W91111013 Interchangeable blade for torque screwdriver TX 20 •
W91100013 Screwdriver Torx TX 20 •
W91500013 Clamping screws for inserts Torx TX 20 / M4.5 x 10.5 •
