Page 314 - Carbide drills I Thread cutting tools 2023

v c
v f
v f
n
P
d
n
v c
v f
n
v c
Application Material G [mm] [mm] 1.0 x d [min ] -1 [100%] 1.5 x d [min ] -1 [100%] 2.0 x d [min ] -1 [100%]
Stainless steel G 1/8 9.728 0.907 10 325 295 8 260 236 6 195 177
ferritc/martensitic G 1/4 13.157 1.337 10 240 321 8 195 261 6 145 194
G 3/8 16.662 1.337 10 190 254 8 155 207 6 115 154
G 1/2 20.955 1.814 10 150 272 8 120 218 6 90 163
Stainless steel G 1/8 9.728 0.907 5 165 150 4 130 118 3 100 91
[Cr-Ni/1.4301] G 1/4 13.157 1.337 5 120 160 4 95 127 3 75 100
G 3/8 16.662 1.337 5 95 127 4 75 100 3 55 74
G 1/2 20.955 1.814 5 75 136 4 60 109 3 45 82
Stainless steel G 1/8 9.728 0.907 6 195 177 5 165 150 4 130 118
[Cr-Ni-Mo-.../1.4571] G 1/4 13.157 1.337 6 145 194 5 120 160 4 95 127
G 3/8 16.662 1.337 6 115 154 5 95 127 4 75 100
G 1/2 20.955 1.814 6 90 163 5 75 136 4 60 109

Heat resistant steel G 1/8 9.728 0.907 4 130 118 3 100 91 - - -
[17-4 PH] G 1/4 13.157 1.337 4 95 127 3 75 100 - - -
G 3/8 16.662 1.337 4 75 100 3 55 74 - - -
G 1/2 20.955 1.814 4 60 109 3 45 82 - - -
