Page 315 - Carbide drills I Thread cutting tools 2023
P. 315
Taps x-tap
Inox
Stainless
TRIBO
Article-N°. ø-Code MF
Example: ET1475
Order-N°. ET1475 551 G
Ø d UN
Code d P(TPI) (mm) L l l 1 l 3 d 2 a
551 G 1/8 28.0 9.728 90 10.00 35.0 33.0 7.0 5.5 3 8.85* • EG
552 G 1/4 19.0 13.157 100 14.00 39.0 37.0 11.0 9.0 4 11.90* •
553 G 3/8 19.0 16.662 100 14.00 39.0 37.0 12.0 9.0 4 15.40* •
554 G 1/2 14.0 20.955 125 20.00 65.0 63.0 16.0 12.0 5 19.20* •
* The given dimension is out of norm
fraisa.com
313
