INDEXABLE DRILLS IDI-SK (continued) DC 6.8-21.9 DC DC 22.0-25.9 KCH LF PL BCH SIG

DCM Drill Heads for Cast Iron

Dimensions

Designation
DC
LF
PL
IDI 232-SK
140
23.0
1.62
30.0
•
IDI 234-SK
30.0
23.40
1.64
6.14
23.0
4.260
140
•
IDI 236-SK
23.0
6.11
4.290
140
30.0
23.60
1.65
•
IDI 237-SK 23.20 6.18 4.220 BCH KCH SIG SSC (1) • IC908
140
30.0
23.0
1.66
23.70
6.09
4.310
IDI 238-SK 23.80 6.07 4.330 1.67 30.0 140 23.0 •
IDI 240-SK 24.00 6.43 4.370 1.68 30.0 140 24.0 •
IDI 241-SK 24.10 6.41 4.390 1.69 30.0 140 24.0 •
IDI 243-SK 24.30 6.38 4.420 1.70 30.0 140 24.0 •
IDI 244-SK 24.40 6.36 4.440 1.71 30.0 140 24.0 •
IDI 245-SK 24.50 6.34 4.460 1.72 30.0 140 24.0 •
IDI 249-SK 24.90 6.27 4.530 1.74 30.0 140 24.0 •
IDI 250-SK 25.00 6.45 4.550 1.75 30.0 140 25.0 •
IDI 251-SK 25.10 6.43 4.570 1.76 30.0 140 25.0 •
IDI 254-SK 25.40 6.38 4.620 1.78 30.0 140 25.0 •
IDI 255-SK 25.50 6.36 4.640 1.79 30.0 140 25.0 •
IDI 258-SK 25.80 6.30 4.700 1.81 30.0 140 25.0 •
IDI 259-SK 25.90 6.29 4.710 1.81 30.0 140 25.0 •
• For cutting conditions see pages 101-105
(1) Seat size code
For tools, see pages: DCM-3.5D (7.5-20.9 mm) (92) • DCM-3D (7.5-25.9 mm) (92) • DCM-5D (7.5-25.9 mm) (93) • DCM-8D (10-25.9 mm) (93) • DCT (M8-M24) (134)
