INDEXABLE DRILLS • The DR-DH drills will be supplied upon request. For a quotation, please contact ISCAR headquarters,
providing all necessary hole and drill details (See following requested information form).
Requested Information Form for Deep Hole Drill Design
Telephone no.
Company name
Address
Customer no.
Contact person
Workpiece Date
Product name: Hole diameter:
Hole depth: No. of holes: Tolerance (of hole):
Surface finish (Rz, Ra...): Deviation (mm/100): Straightness (mm/100):
Material
Material (DIN, AISI, JIS...):
Hardness (HB, HS, HRC...):
Condition: o Quenched o Tempered o Cast o Annealed
o Other
Machine
Machine supplier name:
Machine type/model: o NC lathe o Machining center o Horizontal o Vertical
Rigidity: o Good o Normal o Poor
Spindle power (kW):
Tool and/or workpiece rotation (TR/WR):
o Tool and workpiece o Rotating workpiece (WR) o Rotating tool (TR)
Type of Coolant
Water based: o Soluble o Emulsion %
Oil based: o Coolant Pressure (bar): Coolant Volume (L/min):
Hole Data
Need a pre-hole drill quoation o Pre-drilled hole size % (mm/inch)
