ISOTURN TOOLS MWLNR/L-W 16.0 16.0 WF 16.0 LH MWLNR..-W LF H B WF 23.0 MWLNR..-06SW Right-hand shown 95°

HF
95°
Top Wedge Lock External
Tools Carrying Trigon Inserts
LF
Insert
H
Designation
HF
B
WF
LH
16.00
MWLNR/L 1616H-06SW
WNMG 06T3
100.00
MWLNR/L 2020K-06W
25.00
20.0
WNMG 06T3
20.0
125.00
20.0
25.0
MWLNR/L 2525M-06W
WNMG 06T3
25.0
150.00
25.0
32.00
25.0
25.0
MWLNR/L 2020K-08W
30.0
20.0
20.0
25.00
125.00
20.0
25.0
150.00
32.00
30.0
MWLNR/L 2525M-08W
25.0
25.0
WNMG 0804
32.0
32.0
35.0
WNMG 0804
MWLNR/L 3232P-08W
170.00
32.0
40.00
For inserts, see pages: WNGG-F3N (209) • WNMG-CERMET (136) • WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137) WNMG 0804
• WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-SF (138)
• WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216) • WNGA-M3 (CBN) (224)
• WNGA-MC/M6 (CBN) (224)

Spare Parts
Designation
(a)
MWLNR/L 1616H-06SW IWSN 322W IWSN 3-2W * ZNW 3W SR 14-564 LC 250 SET 1 HW 2.5
(a)
MWLNR/L 2020K-06W IWSN 322W IWSN 3-2W * ZNW 3W SR 14-564 LC 250 SET 1 HW 2.5
MWLNR/L 2525M-06W IWSN 322W IWSN 3-2W * ZNW 3W SR 14-564 LC 250 SET 1 HW 2.5
(a)
(b)
MWLNR/L 2020K-08W IWSN 433 IWSN 433M * ZNW 4W SR M4X8 LC 252 SET 1 HW 3.0
(b)
MWLNR/L 2525M-08W IWSN 433 IWSN 433M * ZNW 4W SR M4X8 LC 252 SET 1 HW 3.0
MWLNR/L 3232P-08W IWSN 433 IWSN 433M * ZNW 4W SR M4X8 LC 252 SET 1 HW 3.0
(b)
* Optional, should be ordered separately
(a) Use IWSN 3-2W optional seat for WNMG 0604.. inserts
(b) Use IWSN 433M optional seat for WNMG 0804..-TNM inserts

MWLNR/L-13W 95°
Top Wedge Lock External HF H 95°
Toolholders for Large
Trigon Inserts WF B
LH
LF
Right-hand shown
Designation H B HF LF LH WF Insert
MWLNR/L 3232P-13W 32.0 32.0 32.0 170.00 45.0 40.00 WNMG 1306
MWLNR/L 4040R-13W 40.0 40.0 40.0 200.00 45.0 50.00 WNMG 1306
For inserts, see pages: WNMA/WNMA-WG (143) • WNMG-TNM (142)

Spare Parts
Designation
MWLNR/L-13W IWSN 635 ZNW 6W SR 14-570 LC 253 HW 4P SPR 17-362 SR 17-362 WA M8
GAMF GAMP
PWLOR/L-IQ HF H 95° 95°
Lever Lock and Dovetail Pocket
Rigid Clamping Tools Carrying
Unique Double-Sided WF B
Trigon Inserts LH
95˚ Right-hand shown
LF
Designation H HF B LF LH WF GAMP GAMF Insert
PWLOR/L 2525M-10-IQ 25.0 25.0 25.0 150.00 25.0 32.00 -6.0 -6.0 WOMG 1007-IQ
PWLOR/L 3232P-10-IQ 32.0 32.0 32.0 170.00 30.0 40.00 -6.0 -6.0 WOMG 1007-IQ
PWLOR/L 3232P-13-IQ 32.0 32.0 32.0 170.00 30.0 40.00 -6.5 -6.5 WOMG 1306-IQ
PWLOR/L 4040S-13-IQ 40.0 40.0 40.0 250.00 30.0 48.00 -6.5 -6.5 WOMG 1306-IQ
For inserts, see pages: WOMG-10-T3P-IQ (136) • WOMG-13-R3P-IQ (137)

Spare Parts
Designation
PWLOR/L 2525M-10-IQ TWN 5-4-IQ SP D1.5-L10 (a) SR LCS 5 LR 5 HW 3.0
PWLOR/L 3232P-10-IQ TWN 5-4-IQ SP D1.5-L10 (a) SR LCS 5 LR 5 HW 3.0
PWLOR/L 3232P-13-IQ TWX 6-IQ SP 5 (a) SR 10402352 LCL 20C-NX HW 4.0
PWLOR/L 4040S-13-IQ TWX 6-IQ SP 5 (a) SR 10402352 LCL 20C-NX HW 4.0
(a) Seat Pin
