Fonçage-tournage
644X5 Einstechen und drehen
Grooving and turning

R
5°

R
E L
1°
R
1° 8

R

P P
M M
N N N N
S S
TiAlN N (µk20) HN (µk10)
E L R Art. N° HTA
Arête de coupe vive 1.5 3 0.08 644X5-1.5-R08  
Scharfe Schneidkante 2 4 0.08 644X5-2.0-R08  
Sharp edge 2 4 0.15 644X5-2.0-R15  
2.5 6 0.08 644X5-2.5-R08  
2.5 6 0.15 644X5-2.5-R15  
3 6 0.08 644X5-3.0-R08  
3 6 0.15 644X5-3.0-R15  

Arête de coupe honée 1.5 3 0.08 644X5-1.5-R08-EP  
Gehonte Schneidkante 2 4 0.08 644X5-2.0-R08-EP  
Honed edge 2 4 0.15 644X5-2.0-R15-EP  
2.5 6 0.08 644X5-2.5-R08-EP  
f min: 0.02 mm/U 2.5 6 0.15 644X5-2.5-R15-EP  
3 6 0.08 644X5-3.0-R08-EP  
3 6 0.15 644X5-3.0-R15-EP  

5.26
