Fonçage-tournage
Einstechen und drehen 634X10 / 644X10
Grooving and turning

L R
10°

R
E L
1°
R
1° 8

L R

P P P P
M M M M
N N N N N N N N
S S S S
TiAlN N (µk20) HN (µk10) TiAlN N (µk20) HN (µk10)
E L R Art. N° HTA Art. N° HTA
0.8 2 0 634X10-0.8   644X10-0.8    
1.0 2.5 0 634X10-1.0   644X10-1.0  
1.0 2.5 0.08 634X10-1.0-R08   644X10-1.0-R08  
1.2 3 0 - 644X10-1.2   
1.2 3 0.08 - 644X10-1.2-R08  
1.5 3 0 634X10-1.5   644X10-1.5   
1.5 3 0.08 634X10-1.5-R08   644X10-1.5-R08   
1.5 3 0.15 634X10-1.5-R15   644X10-1.5-R15  
1.8 4 0 - 644X10-1.8  
2 4 0 634X10-2.0   644X10-2.0  
2 4 0.08 634X10-2.0-R08   644X10-2.0-R08  
2 4 0.15 634X10-2.0-R15   644X10-2.0-R15  
2.5 6 0 634X10-2.5   644X10-2.5  
2.5 6 0.08 634X10-2.5-R08   644X10-2.5-R08  
2.5 6 0.15 634X10-2.5-R15   644X10-2.5-R15  
3 6 0 634X10-3.0   644X10-3.0  
3 6 0.08 634X10-3.0-R08   644X10-3.0-R08  
3 6 0.15 634X10-3.0-R15   644X10-3.0-R15  
5.27
