Filetage
636X / 646X Gewinde drehen
Threading

L R
3°

R
A L
E/2 E

Profil partiel
Teilprofil
Partial profile

L R

P P
M M
N N N N
S S

A E L R Art. N° TiAlN N (µk20) Art. N° TiAlN N (µk20)
55° 1.5 4 0 636X3-55-1.5   646X3-55-1.5  
55° 2.0 6 0.03 636X3-55-2.0-R03   646X3-55-2.0-R03  
60° 1.5 4 0 636X3-60-1.5   646X3-60-1.5  
60° 2.0 6 0.03 636X3-60-2.0-R03   646X3-60-2.0-R03  
60° 2.0 6 0.06 636X3-60-2.0-R06   646X3-60-2.0-R06  
60° 3.0 8 0.06 636X3-60-3.0-R06   646X3-60-3.0-R06  
60° 3.0 8 0.12 636X3-60-3.0-R12   646X3-60-3.0-R12  

5.32
