Filetage
Gewinde drehen 636X-M / 646X-M
Threading

L R
3°

0.55xP L
60°
E
L1

Profil complet métrique
Metrisches Vollprofil
Metric full profile

L R

P P
M M
N N N N
S S
Pas
Steigung
Pitch TiAlN N (µk20) TiAlN N (µk20)
L L1 P Art. N° Art. N°
1.0 3 3 0.25 636X3-M-0.25   646X3-M-0.25  
1.0 3 3 0.30 636X3-M-0.30   646X3-M-0.30  
1.0 3 3 0.35 636X3-M-0.35   646X3-M-0.35  
1.0 3 3 0.40 636X3-M-0.40   646X3-M-0.40  
1.0 3 3 0.45 636X3-M-0.45   646X3-M-0.45  
1.0 3 3 0.50 636X3-M-0.50   646X3-M-0.50  
1.5 5 5 0.60 636X3-M-0.60   646X3-M-0.60  
1.5 5 5 0.70 636X3-M-0.70   646X3-M-0.70  
1.5 5 5 0.75 636X3-M-0.75   646X3-M-0.75  
1.5 5 5 0.80 636X3-M-0.80   646X3-M-0.80  
2.0 7 5 1.00 636X3-M-1.00   646X3-M-1.00  
2.0 7 5 1.25 636X3-M-1.25   646X3-M-1.25  
2.0 7 5 1.50 636X3-M-1.50   646X3-M-1.50  

5.33
