MACHOS PARA ROSCAR NANO ž THREAD TAPS NANO                                                    CLASSIC  SYNCHRO



                                                   TAN                     TAZ                 CMS
                          Desde página:          Materiales normales     Materiales tenaces   Materiales frágiles
                          From page:             Normal materials        Tough materials      Brittle materials
                          M                 338   338  338   338    339  339   339   339     340     340
                          MF                341   341  341   341    342  342   342   342     343     343
                          UNC               344   344  344   344    345  345   345   345     346     346
                          UNF               347   347  347   347    348  348   348   348     349     349
                          S                 350   350  350   350    351  351   351   351     352     352
                          SF                353   353  353   353    354  354   354   354     355     355
                          SL                356   356  356   356    357  357   357   357     358     358














 Clasificación de los materiales  Material classification                                                CMS50VS
                        Vc                    TAN40  TAN40VS  TAN50  TAN50VS  TAZ40  TAZ40VS  TAZ50  TAZ50VS  CMS50
                    (m/min) Guide Line
             Ø 0.3 - 1.4 mm  Ø 1.4 - 2.8 mm
                             Ø 1.4 - 2.8 mm
             Ø 0.3 - 1.4 mm
           Estándar  Recubrimiento  Estándar  Recubrimiento
           Standard  Coated  Standard  Coated
      11           4 - 10          12 - 20                                                                  11
      12           4 - 10          12 - 20                                                                  12
      13           4 - 10          12 - 20                                                                  13
      14           4 - 10          12 - 20                                                                  14
      15                                                                                                    15
      16                                                                                                    16
      17                                                                                                    17
      18                                                                                                    18
      21           4 - 10          12 - 20                                                                  21
      22           4 - 10          12 - 20                                                                  22
      23            3 - 6           6 - 12                                                                  23
      24            3 - 6           6 - 12                                                                  24
      31           4 - 10          12 - 20                                                                  31
      32           4 - 10          12 - 20                                                                  32
      41   2 - 4    2 - 4   4 - 8   4 - 8                                                                   41
      42   2 - 4    2 - 4   4 - 8   4 - 8                                                                   42
      51                                                                                                    51
      52                                                                                                    52
      53                                                                                                    53
       61          4 - 10          12 - 20                                                                   61
       62  4 - 10  4 - 10  12 - 20  12 - 20                                                                  62
      63   4 - 10  4 - 10  12 - 20  12 - 20                                                                 63
       64          4 - 10          12 - 20                                                                   64
      71           4 - 10          12 - 20                                                                  71
      72           4 - 10          12 - 20                                                                  72
      73           4 - 10          12 - 20                                                                  73
      74           4 - 10          12 - 20                                                                  74
      81           4 - 10          12 - 20                                                                  81
      82                                                                                                    82
      83           4 - 10          12 - 20                                                                  83
      91   4 - 10          12 - 20                                                                          91
      92           4 - 10          12 - 20                                                                  92
      93           4 - 10          12 - 20                                                                  93
      94           4 - 10          12 - 20                                                                  94
       Óptima con aire       Aceptable con aire        Limitada          Los valores indicados son orientativos.  445
       Optimal with air      Suitable with air         Limited           The indicated values are a guideline.
