DISEÑO CONSTRUCTIVO DE LOS MACHOS PARA ROSCADO
        POR LAMINACIÓN
        CONSTRUCTIONAL DESIGN OF THREAD FORMING TAPS



                                                        Diseño según DIN             Design according to DIN
                                                        Dimensiones generales        General dimensions
         ~ DIN 2174 (M - MF)     FS3..; FAS3..; FPS3..;  Machos para roscado por lamina- Machine thread formers with
         ~ DIN 2184-1 (UNC - UNF)                        ción con mango DIN reforzado  reinforced DIN shank



         ~ DIN 2174 (M - MF)     FAS4..; FPS4..;         Machos para roscado por lamina- Machine thread formers with
         ~ DIN 2184-1 (UNC - UNF)                        ción con mango DIN pasante  reduced DIN shank
         ~ DIN 2189 (G)




                                                        Diseño según el estándar de  Design according to
                                                        fábrica de DC                DC standards
                                                        Dimensiones generales        General dimensions

         DC / ~ DIN 2174         FAS5..; FPS5..;         Machos para roscado por lamina- Extra-long machine thread formers
                                                         ción extra largos con mango DIN  with reinforced DIN shank
                                                         reforzado                   Overall length as per norm DC,
                                                         Longitud total según el estándar   shank dimensions similar to
                                                         de fábrica DC, dimensiones del   DIN 2174
                                                         mango según DIN 2174

         DC / ~ DIN 2174         FAS6..; FPS6..;         Machos para roscado por lamina- Extra-long machine thread formers
                                                         ción extra largos con mango DIN  with reduced DIN shank
                                                         pasante                     Overall length as per norm DC,
                                                         Longitud total según el estándar   shank dimensions similar to
                                                         de fábrica DC, dimensiones del   DIN 2174
                                                         mango según DIN 2174
