≤ Ø 25.4 > Ø 25.4
DIN 371
PM HSSE
M ISO DIN 13 DIN 376

Z Z320V«4 Z420V«4 Z320VS«4 Z420VS«4

N

Z320V-4 V 11 12 13 21 32

Z420V-4 V 11 12 13 21 32

Z320VS-4 VS 11 12 13 14 21 22
23 32 61 63 94

Z420VS-4 VS 11 12 13 14 21 22
23 32 61 63 94

B B B B
a
d 2
4 x P 4 x P 4 x P 4 x P
d 1
l
2
l
3 l P
1
Ø d 1 P l 1 l 2 l 3 d 2 a ID ID ID ID
M mm mm mm mm mm mm
* 1.6 0.35 40 8 2.5 2.1 2 1.25 l 142671
* 2 0.4 45 8 2.8 2.1 2 1.6 l 111613
2.5 0.45 50 10 2.8 2.1 3 2.05 l 111455 l 143683
2.6 0.45 50 10 2.8 2.1 3 2.15 l 142672
3 0.5 56 12 18 3.5 2.7 3 2.5 l 104669 l 104830
4 0.7 63 14 21 4.5 3.4 3 3.3 l 104670 l 104831
5 0.8 70 15 25 6 4.9 3 4.2 l 104671 l 104832
6 1 80 17 30 6 4.9 3 5 l 104672 l 104833
8 1.25 90 20 35 8 6.2 3 6.8 l 104673 l 104834
10 1.5 100 22 39 10 8 3 8.5 l 104668 l 104835
12 1.75 110 24 9 7 3 10.2 l 104723 l 104836
14 2 110 28 11 9 3 12 l 142673 l 143684
16 2 110 30 12 9 3 14 l 105068 l 111569
18 2.5 125 33 14 11 4 15.5 l 142674
20 2.5 140 36 16 12 4 17.5 l 105069 l 111570
22 2.5 140 36 18 14.5 4 19.5 l 146003
24 3 160 39 18 14.5 4 21 l 142675 l 150017
30 3.5 180 45 22 18 4 26.5 l 142676

*Z320V-3 2.5 x P
